Electra DNG 18 - Page 105

15-8
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01
Service Manual - DNG Series
15.10 Outdoor Unit: GC 18 ST 1PH
SP No. Part No. Description Qty
1 4517144 FAN COVER PP+UV 1
2 452795700 PAINTED LEFT CABINET ASS
Y
1
3 452989200 Base welding plate assy. 1
4 4516786 PAINTED RIGHT CABINET ASS
Y
1
5 4516985 Partition Plate 1
6 455000506 Compressor Capacitor With Screw 45uF (CBB65) 1
7 455000104 Double patch Capacitor for fan motor 4uF (CBB61S) 1
8 204107 Cable clip Nylon 2
9 4521744 3 Poles Terminal Block (4mm2) 1
10 4522469 4 LEVEL TERMINAL BLOC
K
1
11 4521733 3 Poles Terminal Block ( 6mm2) 1
12 4521340 Controller Bo
x
1
13 4525427 Clip for capacitance(d=50) 1
14 453089900 Compressor Assy.PA200X2CS-4KU1 1
15 4519000 Spring of compressor heater 1
16 4517345 COMPRESSOR WIRE ASSY. 2.5mm2 1
17 4526922 heater for compressor 1
18 4516766 PAINTED VALVE PLATE ASS
Y
1
19 4526530 LOW PRESS VALVE (R410A) 1
20 4526531 High press valve(R410A) 1
21 4526931 filter welding assy. 2 1
22 4526839 filter welding assy. 1
23 4523145 R.lifter 1
24 452821900 Capillary assy. for cooling 1
25 4523338 Accumulator assy. 1
26 452977200 Low pressure pipe 1
27 452976200 Suction pipe 1 1
28 4526291 Muffler 1
29 4525938 PAINTED RIGHT-BACK CABINET ASS
Y
1
30 452977000 Condenser pipe assy. 1
31 452976800 Discharge pipe 2 1
32 4517028 PAINTED LEFT-BACK GRILL 1
33 4516758 SMALL HANDLE 1
34 452976000 Discharge pipe 1 1
35 452821300 Condenser-Distributing Soldering Assy.GC-18ST R410
A
1
36 452988800 Insulation for compressor PA215/240 1
37 4526509 MOTOR BRAKECT (new) 1
38 4526864 motor YYK85E-6 1
39 4526585 connect for motor backet 1
40 4526510 FAN D=460mm (3 blade) 1
41 4523141 Hexagon locked nut M10 1
42 4516788 PAINTED TOP COVER ASS
Y
1
