EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01
Service Manual - DNG Series
15.12 Outdoor Unit: GC 18 RC 3PH
SP No. Part No. Description Qty
1 4517144 Grid A 1
2
452795700 left-cover 1
3
452881901 base panel 1
4
4516786 right cove
r
1
5
4516985 partition 1
6
455000104 capacitance for fan 1
7
204107 cable clip 1
8
452872000 cantactor
2
9
4522469 4 bit terminal 1
10
4521289 6 bit terminal 1
11
4521695 5 bit terminal 1
12
453136700 electrical box 1
13
4519695 mix and missing phase device 1
14
453019600 compressor NN21YDAMT 1
15
4519000 Spring fo compressor heater 1
16
4517131 cable for compressor 1
17
4520870 heate
r
1
18
4516766 valve -panel 1
19
453163700 low pressure valve 1
20
4526531 high pressure valve 1
21
4526839 filter assy 1
22
4526931 filter assy 1
23
4523145 big handle 1
24
4526840 sing-way welding ass
y
1
25
452891400 accumulation 1
26
452883700 suction tube 1
27
452883800 low pressure tube 1
28
453160700 condenser tube 1
29
4526291 muffler 1
30
4525938 right-back cover 1
31
4526522 4-way valv
e
1
32
4526589 coil for 4-way valv
e
1
33
452890700 discharge tube 1
34
453251600 4-way welding ass
y
1
35
4517028 left-back grid 1
36
4516758 small handle 1
37
453172900 discharge tube 1
38
452796500 condenser welding ass
y
1
39
452891300 insulation for compressor 1
40
452883600 suction tube 1
41
4526509 support for motor 1
42
4526864 motor 1
43
452907400 connect panel 1
44
4526510 fan 1
45
4523141 nut 1
46
4516788 top cove
r
1
