15-12
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01
Service Manual - DNG Series
15.14 Outdoor Unit: GC 18 ST 3PH
SP No. Part No. Description Qty
1 4517144 Fan cover 1
2 452795700 Painted left cabinet assy 1
3 452881901 Base plate paint assy. 1
4 4516786 Painted right cabinet assy 1
5 4516985 Partition plate 1
6
455000104 capacitance for fan
1
7
204107 cable clip
1
8
452872000 cantactor
2
9
4522469 4 bit terminal
1
10
4521289 6 bit terminal
1
11
4521695 5 bit terminal
1
12
453136700 electrical box
1
13
4519695 mix and missing phase device
1
14 453019600 Compressor assy 1
15 4519000 Spring for compressor heater 1
16 4517131 Compressor wire assy 1
17 4520870 Heater for compressor 1
18 4516766 Painted valve plate assy 1
19 453163700 Low pressure valve(R410A) 1
20 4526531 High pressure valve(R410A) 1
21 4526839 Filter assy 1 1
22 4526931 Filter assy 2 1
23 4523145 R.lifter 1
24 452821900 Capillary welding assy. 1
25 452891400 Accumulation assy 1
26 452893600 Suction pipe 1
27 452883600 Suction pipe assy. 2 1
28 4526291 Muffler 1
29 4525938 Painted right-back cabined assy 1
30 453160800 condenser pipe assy. 1
31 453160600 Discharge pipe 1 1
32 4517028 Painted left-back grill 1
33 4516758 Small handle 1
34 453160500 Discharge pipe 2 1
35 452821300 Condenser and distributor welding assy. 1
36 452891300 Insulation for compressor 1
37 4526509 Moter brakect (new) 1
38 4526864 motor YYK85E-6 1
39 452907400 Hook for condenser 1
40 4526510 FAN D=460mm (3 blade) 1
41 4523141 M10 Hexagon locked nut M10 1
42 4516788 Painted top cover assy 1
