Electra DNG 18 - Page 117

15-20
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01
Service Manual - DNG Series
15.22 Outdoor Unit: OU7-24 ST 3PH
No. SP No. Part No. Description Qty
1 1 190443 HEATER CRANKCASE MITSUBISHI C
O
1
2 3 402283 SUCTION ACCUMULATOR 3"x5/8" 3. 1
3 4 402494 BOARD TPHN 3C 1
4 5 433705 NEW BASE ASSY OU 2005 LOCAL 1
5 6 433753 COMPRESSOR NN27YDAMT 1
6 7 433816 SUCTION ASSY OU7 R410A 1
7 8 433817 TUBING ASSY OU7 ST R410A 1
8 9 433845 CAPILLARY ASSY OU7-24 ST R410A 1
9 11 433846 COIL OU7-24 ST 1
10 12 433847 GAS VAVE ASSY OU7 ST R410A 1
11 13 434062 MOTOR 86W,2S,OU7-24 1
12 14 434716 THERMISTOR+CAP WTH CONNECTO
R
1
13 15 436357 SMALL ELECTRICAL COVER OU 1
14 16 436358 OU LEADING HANDLE 1
15 17 437045 UPPER COVER EL13 OU LARGE 1
16 18 437091 OU SQUARE FAN GUARD 1
17 19 437229 ELECTRICAL BOX TPHN 1
18 21 437278 COMPRESSOR WIRING OU7/8-3PH MI 1
19 22 439329 FRONT COVER/COLLECTOR OU7-35/
9
1
20 24 439342 MOTOR SUPPORT OU7 1
21 25 439795 3PH MOTOR PROTECTOR 1
22 44 442007 CAPACITOR 6mF 400V P1/P2 1
23 45 4529604 AXIAL FAN D493*143 1
