Electra DNG 18 - Page 122

15-25
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01Service Manual - DNG Series
15.27 Outdoor Unit: OU8-30 ST 1PH
Item Code Item Description Quantity
Drawing
Number
437045 UPPER COVER EL13 OU LARGE 1 1
402930 SIDE PANEL OU8-33 1 2
436357 SMALL ELECTRICAL COVER OU 1 3
439929 FRONT PANEL/COLLECTOR OU8-30 1 4
437091 OU SQUARE FAN GUARD 1 5
433705 NEW BASE ASSY OU 2005 LOCAL 1 6
433834 COIL OU8-30 ST GR R410A 1 7
4529604 AXIAL FAN D493*143 1 8
434062 MOTOR 86W,2S,OU7-24 1 9
403996 SIDE GUARD OU8-33Z 1 10
436358 OU LEADING HANDLE 1 11
439775 MOTOR SUPPORT OU8 1 12
190443 HEATER CRANKCASE MITSUBISHI 1 13
433297 COMPRESSOR NN33VAAMT 1 14
433830 CAPILLARY ASSY OU8-30 R410A ST 1 15
433833 TUBING ASSY OU8-30 ST R410A 1 16
402495 BOARD TPHN 5B 1 17
442007 CAPACITOR 6mF 400V P1/P2 1 18
434716 THERMISTOR+CAP WTH CONNECTOR 1 19
442016 CAPACITOR 55mF 400V P1/P2 1 20
437274 COMPRESOR WIRING OU7/8-1PH 1 21
402284 SUCTION ACCUMULATOR 5" x 3/4" 1 22
439928 OUTLET PLASTIC RING OU8 1 23
437229 ELECTRICAL BOX TPHN 1 24
439656 SIDE COVER OU-8/10 1 28
