15-36
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01
Service Manual - DNG Series
15.38 Outdoor Unit: OU10-36 RC 3PH
Item Code Item Description Quantity
Drawing
Number
437045 UPPER COVER EL13 OU LARGE 1 1
439655 SIDE PANEL OU10 1 2
436357 SMALL ELECTRICAL COVER OU 1 3
439653 FRONT PANEL OU10 1 4
439662 GRILLE OU10 2 5
433294 NEW BASE ASSY OU 2005 EXPORT 1 6
433854 COIL OU10-36 GR HDR R410A 1 7
439650 AXIAL FAN D400*112 2 8
439865 MOTOR 70W,3S,OU10-38 2 9
430838 SIDE NET PANEL EL13 OU10-44Z 1 10
436358 OU LEADING HANDLE 1 11
439657 MOTOR SUPPORT OU10 1 12
190443 HEATER CRANKCASE MITSUBISHI 1 13
433855 COMPRESSOR NN40YCAMT 1 14
433857 CAPILLARY ASSY OU10-36 R410A 1 15
433865 TUBING ASSY OU10-36 R410A 1 16
402494 BOARD TPHN 3C 1 17
442017 CAPACITOR 3mF 400V P1/P2 2 18
434716 THERMISTOR+CAP WTH CONNECTOR 1 19
437280 COMPRESSOR WIRING OU10-3PH 1 21
402189 SUCTION ACCUMULATOR 5" x 3/4" 1 22
439661 CONES OU10 2 23
437229 ELECTRICAL BOX TPHN 1 24
439795 3PH MOTOR PROTECTOR 1 25
436352 RAISING HANDLE OU10 1 26
439656 SIDE COVER OU-8/10 1 28
442466 VALVE COIL L700 MOLEX-SANHUA 1 33
