5-9
PERFORMANCE DATA & PRESSURE CURVES
Revision Y05-01Service Manual - DNG Series
5.7 DNG 30, OU8- 30 1PH / 3PH
5.7.1 Cooling Capacity (kW)
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
Entering Air WB/DB ID Coil(
o
C)
15/21 17/24 19/27 21/29 23/32
TC
8.67 9.18 9.61 10.03 10.37
15 SC
6.27 6.65 7.01 6.85 6.96
PL
2.13 2.13 2.14 2.15 2.15
TC
8.59 9.10 9.52 9.95 10.29
20 SC
6.12 6.50 6.87 6.67 6.82
PL
2.30 2.31 2.33 2.34 2.35
TC
8.25 8.84 9.35 9.78 10.12
25 SC
6.10 6.53 6.91 6.78 6.96
PL
2.48 2.51 2.53 2.55 2.55
TC
7.74 8.33 9.01 9.35 9.69
30 SC
5.79 6.25 6.76 6.62 6.89
PL
2.69 2.72 2.76 2.78 2.79
TC
7.14 7.74
8.50
8.93 9.27
35 SC
5.46 5.93
6.49
6.41 6.67
PL
2.91 2.95
3.00
3.02 3.04
TC
6.46 7.06 7.82 8.25 8.59
40 SC
5.07 5.58 6.13 6.04 6.33
PL
3.13 3.18 3.24 3.27 3.29
TC
5.61 6.21 6.97 7.40 7.74
46 SC
4.61 5.11 5.75 5.64 5.91
PL
3.44 3.49 3.55 3.60 3.64
Entering Air DB
OD Coil(
o
C)
