PERFORMANCE DATA & PRESSURE CURVES
Revision Y05-01Service Manual - DNG Series
5.10 DNG 37, OU10- 36 1PH
5.10.1 Cooling Capacity (kW)
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
Entering Air WB/DB ID Coil(
o
C)
15/21 17/24 19/27 21/29 23/32
TC
10.81 11.45 11.98 12.51 12.93
15 SC
7.92 8.40 8.85 8.65 8.80
PL
2.70 2.70 2.71 2.72 2.73
TC
10.71 11.34 11.87 12.40 12.83
20 SC
7.63 8.11 8.57 8.32 8.50
PL
2.91 2.93 2.95 2.96 2.97
TC
10.28 11.02 11.66 12.19 12.61
25 SC
7.70 8.25 8.72 8.57 8.79
PL
3.15 3.17 3.20 3.23 3.23
TC
9.65 10.39 11.24 11.66 12.08
30 SC
7.32 7.90 8.53 8.36 8.70
PL
3.40 3.45 3.49 3.52 3.53
TC
8.90 9.65
10.60
11.13 11.55
35 SC
6.89 7.50
8.19
8.10 8.43
PL
3.68 3.74
3.80
3.83 3.85
TC
8.06 8.80 9.75 10.28 10.71
40 SC
6.40 7.05 7.75 7.63 8.00
PL
3.97 4.03 4.10 4.14 4.17
TC
7.00 7.74 8.69 9.22 9.65
46 SC
5.82 6.45 7.27 7.13 7.47
PL
4.35 4.42 4.50 4.56 4.61
Entering Air DB
OD Coil(
o
C)
Data
To Next Page
