PERFORMANCE DATA & PRESSURE CURVES
Revision Y05-01Service Manual - DNG Series
5.12 DNG 37, OU10- 36 3PH
5.12.1 Cooling Capacity (kW)
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
Entering Air WB/DB ID Coil(
o
C)
15/21 17/24 19/27 21/29 23/32
TC
10.61 11.23 11.75 12.27 12.69
15 SC
7.77 8.24 8.68 8.49 8.63
PL
2.61 2.61 2.61 2.63 2.64
TC
10.50 11.13 11.65 12.17 12.58
20 SC
7.49 7.96 8.41 8.16 8.34
PL
2.81 2.83 2.84 2.86 2.87
TC
10.09 10.82 11.44 11.96 12.38
25 SC
7.56 8.09 8.56 8.41 8.62
PL
3.04 3.06 3.09 3.12 3.12
TC
9.46 10.19 11.02 11.44 11.86
30 SC
7.18 7.75 8.37 8.21 8.54
PL
3.29 3.33 3.37 3.40 3.41
TC
8.74 9.46
10.40
10.92 11.34
35 SC
6.76 7.35
8.04
7.95 8.27
PL
3.56 3.61
3.67
3.70 3.71
TC
7.90 8.63 9.57 10.09 10.50
40 SC
6.28 6.91 7.60 7.49 7.85
PL
3.83 3.89 3.96 4.00 4.03
TC
6.86 7.59 8.53 9.05 9.46
46 SC
5.71 6.33 7.13 6.99 7.33
PL
4.20 4.27 4.35 4.40 4.45
Entering Air DB
OD Coil(
o
C)
Data
