PERFORMANCE DATA & PRESSURE CURVES
Revision Y05-01Service Manual - DNG Series
5.15 DNG 44, OU10- 44 3PH
5.15.1 Cooling Capacity (kW)
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
Entering Air WB/DB ID Coil(
o
C)
15/21 17/24 19/27 21/29 23/32
TC
12.65 13.39 14.01 14.63 15.13
15 SC
8.93 9.47 9.98 9.75 9.92
PL
3.27 3.27 3.28 3.29 3.30
TC
12.52 13.27 13.89 14.51 15.00
20 SC
8.93 9.49 10.03 9.73 9.95
PL
3.53 3.55 3.57 3.59 3.60
TC
12.03 12.90 13.64 14.26 14.76
25 SC
8.69 9.30 9.84 9.66 9.91
PL
3.81 3.84 3.88 3.91 3.91
TC
11.28 12.15 13.14 13.64 14.14
30 SC
8.25 8.91 9.62 9.43 9.81
PL
4.12 4.17 4.23 4.26 4.27
TC
10.42 11.28
12.40
13.02 13.52
35 SC
7.77 8.45
9.24
9.13 9.50
PL
4.46 4.53
4.60
4.64 4.66
TC
9.42 10.29 11.41 12.03 12.52
40 SC
7.22 7.94 8.74 8.60 9.02
PL
4.80 4.88 4.96 5.01 5.05
TC
8.18 9.05 10.17 10.79 11.28
46 SC
6.56 7.27 8.19 8.04 8.42
PL
5.27 5.35 5.45 5.52 5.58
