11-4
REFRIGERATION DIAGRAMS
Revision Y05-01 Service Manual - DNG Series
11.4 Cooling Model Only
11.2.1 DNG 18 ST
11.5 Cooling Models Only
11.2.1 DNG 24, 30, 37, 44 ST
Strainer
Capillary
tube
port
Service
Flared
connection
Valves
rosserpmoC
Outdoor coil
Indoor coil
Sensor
Sensor
INDOOR UNIT
OUTDOOR UNIT
