INSTALLATION MANUAL 4.7Draining Condensing Water Out of Outdoor Unit
THIS FUNCTION IS ONLY
APPLICABLE FOR HEAT PUMP UNIT
When in heating mode, condensing water formed on outdoor
unit and defrost water produced when defrost can be drained
out to the suitable place through drain line.
Installation method: Insert the outdoor drain coupling into the
25 hole on base plate as per figure. Then connect the drain
tube with the coupling, which will lead condensing water and
defrost water to the suitable place.
Base plate on
outdoor unit
Outdoor drain coupling
