5.2 Outlet air
5.2.1 Overheating thermostat
Description
The outlet overheating thermostat is placed next to the fan motor on the back of the machine.
The outlet overheating thermostat ensures that the machine does not overheat during program operation.
The outlet overheating thermostat opens automatically and has to be reset manually.
Resetting
Disconnect the power to the machine.
Demount the lower rear panel.
Press the reset button (A) on the overheating thermostat.
fig.W00252
Remount the lower rear panel.
Replacement of overheating thermostat
Disconnect the power to the machine.
Demount the lower rear panel.
Disconnect the overheating thermostat and remove it. Connect the new overheating thermostat.
