Electrolux T5675 N2 - Drive Belt and Rear Sealing Replacement

Service Manual
67
11.3 Replacement of the belt around the drum
Disconnect the power to the machine.
Demount the two rear panels.
fig.7215E
Demount the cover panel to the belt tensioner.
On machines with RMC; demount the RMC (A).
fig.7219B
Loosen the belt tensioner with a torque wrench by pulling the tension plate counter clockwise to the bottom.
