Service Manual
Connect the motor cable.
Remount the cover panel and the rear panels.
Note!
The machine will NOT work without the cover panel.
7.2 Replacement of fan motor
Disconnect the power to the machine.
Demount the lower rear panel.
Cut necessary straps and disconnect the fan motor cable.
fig.7235B
Demount the fan motor module. Carefully lift out the fan motor module and put it down with the fan motor cover
downwards.
fig.7227A
