Service Manual
8 Heating unit, electric
8.1 General
Spare part number, effect and voltage are printed on each heating element.
8.2 Replacement of heating element
Disconnect the power to the machine.
Demount the upper rear panel.
fig.7248C
Disconnect the heating sensor (PT100) and the overheat protection (1).
Demount the heating module (2).
Carerfully lift out the heating module and put it upside down with the heating elements facing upwards.
fig.7280
