Service Manual
16 Maintenance
16.1 Clean the fan, the exhaust duct and the fresh-air intake to the room
Check that the following are not clogged by lint and dust or otherwise blocked and clean with a vacuum cleaner:
• The fan. Be careful not to damage the fan.
• Exhaust duct.
• Fresh-air intake to the room.
Check that the exhaust system connections are tight.
16.2 Clean the glide surface for the RMC graphite collector
Clean the glide surface for the RMC graphite collector on the outside of the drum (A).
fig.W00265A
16.3 Clean the area around the drum
Disconnect the power to the machine.
Demount the hinges and remove the door. Remove the upper hinge first.
