Electrolux T5675 N2 - Page 31

Service Manual
31
Remove the screw and washer.
Use a puller to remove the fan from the fan motor.
Remount the fan on the fan motor. Put loctite on the screw and tighten with tightening torque 10 Nm ± 1.0 Nm).
Make sure the shaft gets all the way to the bottom. Use a counterstay (A) in the center of the shaft so you do not dam-
age the motor when remounting.
fig.W00223A
Remount the fan motor module in the machine.
Connect the fan motor cable.
Remount the lower rear panel.
