Service Manual
Remove the screws and the bearing cover (A).
1. Shows a machine without RMC. Remove the bolt (B) and the washer (C).
2. Shows a machine with RMC. Loosen the screw and pull the RMC flange to the side in order to remove the bolt
(B) and the washer (C).
fig.7231A
Carefully lift out the drum and remove the belt.
When remounting the drum, first fasten the new belt temporarely on the outer drum in the machine, then put the drum
in position.
