About the device
2.2 Technicalspecications
PS8016-20DT PS8032-10DT PS8065-05DT PS8032-20DT PS8065-10DT
Mainsinput
Input voltage 90…264V 90…264V 90…264V 90…264V 90…264V
Input voltage with derating - - - - -
Input current at 230V max. 1.8A max. 1.8A max. 1.8A max. 3.2A max. 3.4A
Input current at 100V max. 3.8A max. 3.8A max. 3.8A max. 7.5A max. 7.5A
Input frequency 45…65Hz 45…65Hz 45…65Hz 45…65Hz 45…65Hz
Input fuse T 8A T 8A T 8A T 8A T 8A
Power factor > 0.99 > 0.99 > 0.99 > 0.99 > 0.99
Output-Voltage
Nominal voltage U
Nom
16V 32V 65V 32V 65V
Adjustable range
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
Stability at mains fluctuation ±10% ∆U
IN
< 0.02% < 0.02% < 0.02% < 0.02% < 0.02%
Stability at 10…90% load < 0.05% < 0.05% < 0.05% < 0.05% < 0.05%
Ripple LF BWL 20MHz < 4mV RMS < 10mV RMS < 20mV RMS < 8mV RMS < 10mV RMS
Ripple HF BWL 20MHz < 40mV P-P < 100mV P-P < 150mV P-P < 100mV P-P < 150mV P-P
Accuracy* ≤ 0.2% ≤ 0.2% ≤ 0.2% ≤ 0.2% ≤ 0.2%
Resolution of display 10mV 10mV 10mV 10mV 10mV
Remote sense compensation max. 2V max. 2V max. 2V max. 2V max. 2V
Overvoltage protection
threshold (adjustable)
0…17.6V 0…35.2V 0…71.5V 0…35.2V 0…71.5V
Output-Current
Nominal current I
Nom
20A 10A 5A 20A 10A
Adjustable range
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
Stability at mains fluctuation ±10% ∆U
IN
< 0.05% < 0.05% < 0.05% < 0.05% < 0.05%
Stability at 0…100% ∆U
OUT
< 0.15% < 0.15% < 0.15% < 0.15% < 0.15%
Ripple LF BWL 20MHz < 10mA RMS < 7mA RMS < 3mA RMS < 10mA RMS < 3mA RMS
Ripple HF BWL 20MHz < 60mA P-P < 35mA P-P < 12mA P-P < 65mA P-P < 25mA P-P
Accuracy* ≤ 0.2% ≤ 0.2% ≤ 0.2% ≤ 0.2% ≤ 0.2%
Resolution of display 10mA 10mA 1mA 10mA 10mA
Transient recovery time 10….90% load < 2ms < 2ms < 2ms < 2ms < 2ms
Output-Power
Nominal power P
Nom
320W 320W 325W 640W 650W
Nominal power at derating - - - - -
Adjustable range - - - - -
Accuracy* - - - - -
Resolution of adjustment - - - - -
Efficiency ≤ 90.5% ≤ 89% ≤ 93% ≤ 90.5% ≤ 91%
Miscellaneous
Cooling by fan by fan by fan by fan by fan
Ambient temperature 0….50°C 0….50°C 0….50°C 0….50°C 0….50°C
Storage temperature -20….70°C -20….70°C -20….70°C -20….70°C -20….70°C
Humidity rel. < 80% < 80% < 80% < 80% < 80%
Dimensions (WxHxD) 330x118x308mm 330x118x308mm 330x118x308mm 330x118x308mm 330x118x308mm
Weight 6,5kg 6,5kg 6,5kg 6,5kg 6,5kg
Sharebus for parallel connection no no no no no
Article number 09200130 09200131 09200132 09200133 09200134
Series connection
Parallel connection
Humidity
Isolation
Safety
EMC standards
Overvoltage class
Protection class
Analogueprogramming
Voltage range
Accuracy set/actual values
Input impedance
Class I
EN 60950
EN 61326, EN 55022 Class B
Class II
possible, up to max. 600V total voltage
possible, max. 30 units, models from 1000W via Share bus
<80%
Input to output: 2500V, Output to enclosure: 500V
0…5V or 0…10V (selectable)
≤
0.2%
approx. 53kΩ
* Related to the nominal value, the accuracy denes the maximum allowed deviation between set value and actual value.
Example: a 80V model has min. 0.2% voltage accuracy. This is 160mV. When setting a voltage of 5V and with an allowed maximum deviation of 160mV, the resulting
actual value could be between 4.84V and 5.16V.
