Resistance Welder MULTISPOT MI-100
Maintenance
47
8.2.4 Empty cooling water tank
Scald hazard
DANGER! Scalding may occur due to hot water coming out!
While pulling out the cooling water hoses hot water may come out. Therefore:
– Wear gloves.
– Pull out water hoses carefully.
Slip hazard
DANGER! Slip hazard due to water coming out!
While pulling out the cooling water hoses water may come out. Therefore:
– Remove water from the floor.
Fig.57: Draining cooling water.
1. Connect the drain hose to the cooling outlet (Fig.57).
2. Have four 10-litre buckets ready at hand to catch the cooling
water.
3. Do one weld without sheet by pushing the trigger of the
welding pliers once. Cooling water will be drained.
4. Turn off the power switch to turn off the pump.
8.3 Measures to be taken after maintenance
When you finish maintenance and before you switch the welder back on, carry out the following:
1. Re-establish any and all connections you loosened and/or removed before. Check for tight fit.
2. Make sure any and all safety devices, covers etc. you may have removed are properly back in
place.
3. Make sure you have properly removed and taken away from the work area any and all tools,
materials etc. you may have used.
4. Clean the work area. If there have been any leaks, spills etc., clean up.
