Resistance Welder MULTISPOT MI-100
Specifications
48
9 Specifications
9.1 Dimensions and weights
Item Value Unit
Height 925 / 36 mm / in
Width 650 / 26 mm / in
Depth 645 / 25 mm /in
Weight (w/o accessories) 100 / 220 Kg / lb
9.2 Power requirements
Power supply
Item Value Unit Value Unit
Mains voltage 400 / 3 ~ / 50/60 V / Ph / Hz 230 / 3 ~ / 50/60 V / Ph / Hz
Admissible voltage range 380 – 415 V (AC) 208 - 240 V (AC)
Power cord 6
AWG 10
mm
2
/ 10 m
/ 33 ft
16
AWG 6
mm
2
/ 10 m
/ 33 ft
Mains fuse, min. 32 A träge 63 A träge
Installed power 42 kVA 42 kVA
Rated output at 50% duty cycle 60 kVA 60 kVA
No load voltage, max. 23 V (DC) 23 V (DC)
weld current, regulated. 12000 A (DC) 12000 A (DC)
Enclosure IP21 IP21
Compressed-air supply
Item Value Unit
Operating pressure, min. – max. 6 – 10
87 – 145
bar
Psi
Quality clean, dry, free of oil
9.3 Supplies
Item Value Unit
Cooling water – tank capacity 33 /9 l / gal
Chlorine-fre disinfectant accor. dosing
instructions
9.4 Working conditions
Ambient conditions
Item Value Unit
Ambient temperature, max.. 40 / 104 °C /°F
Rel Humidity, max.
(no dew)
85 %
