Eliet Prof 6 - Turning and Positioning the Blow Chute and Deflector

35
English
Warning: Before you begin shredding, ensure that the blow chute is set to the
vertical position. Point the blow chute and the deflectors in the desired
direction.
9.6.2. Turning and positioning the blow chute and deflector
• To position the blow chute,
you will need to release the
lever (1), hold the handle on
the blow chute (2) and turn it
to the desired position. Once
the blow chute has been set
to the desired position, the
lever (1) can be retightened.
• To set the deflector in the
desired position, use the
handle (3) to position the
deflector and then retighten
the handle (4) to keep it in
that position.
2
1
3
4
