59
English
TIP:
Use a clean funnel equipped with a filter to prevent the introduction of any dirt.
• Fill the tank with 10 litres - 10 US qt of fresh hydraulic fluid and screw back on the filler plug.
“17.1. Specifications for lubricants and fuel”, page 82
• Wipe off any spilled fluid.
11.4.7. Changing the hydraulic fluid filter
The hydraulic circuit is a closed circuit. As the machine is operating, the fluid is contaminated
by the wear to which the hydraulic elements are subjected, as well as by the poppet valve in the
tank. The fine particles that enter the fluid are filtered out by a filter cartridge. Over time, this
filter cartridge will be changed at the same time as the hydraulic fluid.
This filter is located beneath the hopper, behind the fuel tank.
1
2
1
