15. Equipment specifications
PROF 6 (ZR) PROF 6 Cross Country PROF 6 On Road
Choice of engine B&S Vanguard 14 HP | Subaru 14 HP
Engine starting system electric
Type petrol (UK)/ gas (USA)
Number of cylinders 1
Cubic capacity (cc) 408/404
Horsepower (rpm) 10.3 / 14 (3500)
Engine cooling system Air cooling system
Fuel tank capacity 11 litres - 2,9 US gallons
Max. branch diameter 100 mm - 4”
Output 4 m
3
- 5.5 cubic yard wood chips/hour
Blade shaft 6 discs, 24 Eliet Resist
™
blades/8
Cutting frequency 48,000 cuts/min
Transmission V-type XPA 2240 belt x 2 power bands
Feed roller drive hydraulic Ø 156 mm - 6”
Hydraulic fluid tank 10 litres - 2.6 US gallons
Battery 12V
Power control ELIET ABM (Anti-Block Motor system)
Safe and ergonomic infeed height feeding height: 1,000 mm - 39” / infeed hopper opening: 560 x 600 mm - 22” x 24”
Discharge system
discharge height 1,900 mm/projection distance
0.5 m <> 15 m
foldable blow chute for transport (H: 1,500 mm)
Dimensions (LxWxH)
1,900 x 860 x 1,670 mm
6ft x 34” x 5 1/2ft
low centre of gravity
1,900 x 860 x 1,670 mm
6ft x 34” x 5 1/2ft
1,900 x 1,475 x 1,670 mm
6ft x 5ft x 5 1/2ft
Noise level 115 dB(A) 115 dB(A) 115 dB(A)
Wheel drive 2 x hydraulic motors (32 cc) 2 x hydraulic motors (250 cc) -
Wheels
Wheels 6.5 x 8”
Tracks 150 x 72 x 34 cm
59 x 28 x 13”
-
Weight 362 kg - 798 lbs 441 kg - 973 lbs 425 kg - 937 lbs
Speed regulator option option option
Agricultural wheels Standard - -
