Elmo EV-2000AF - Transmission Specifications; Connection

23
Transmission specifications
· Full duplex start-stop sync. mode
· Start bit : 1 bit
· Data bit : 8 bits
· Stop bit : 1 bit
· Parity bit : None
· X parameter : None
· Baud rate (Communication speed) : 9600bps
Connection
If the RS-232C cable is not correctly connected between the Presenter and the PC, no acknowledgement is transmitted.
Connect the RS-232C cable correctly, and fix it firmly with the connector set screws before the operation.
