Item
Specifications
Power source
Rated current
AC outlet
1 pce. (Max. 400W/Unswitched)
AC120V 60Hz
0.5A
Outside dimensions
500mm(W) X 612mm(D) X 99mm(H) (19.7 X 24.1 X 3.9 in.) - When folded
706mm(W) X 403mm(D) X 575mm(H) (27.8 X 15.9 X 22.6 in.) - When set up
Weight
6 kgs (13.2 lbs) (main body only)
Television system
NTSC compatible
Output terminal
Composite-video output
RCA pin jack/75Ω unbalanced
BNC connector/75Ω unbalanced
S-video output Mini DIN 4P connector/75Ω unbalanced
DC12V output
RS-232CExt. control terminal DSUB 9P connector (male)
1
1
1
1
1
Mini DIN 9P connector (female)
Item
Specifications
Lens f=5.8-70mm (12-time zoom) F1.9-2.6
Shooting area 340mm x 252mm (13.4 X 9.9 in.) max., 16mm x 12mm (0.6 X 0.5 in.) min.
Limit of focus adjustment
At the range of stage surface~150mm (5.9 in.) from the stage surface.
∞-0.5m (20 in.) (with the camera facing sideways and with no close-up lens).
Focusing Auto/manual
Iris
Auto (with level adjustment)
Image pick-up element
1/3" Interline-transfer CCD
Effective picture element
768 (H) x 494 (V)
Total picture elements 811 (H) x 508 (V) (approx. 410,000 pixels)
Image signal processing
Digital signal processing (DSP)
Internal
Resolution More than 470 TV lines (Y signal with horizontal)
More than 350 TV lines (Vertical)
Sync. system
S/N ratio
48 dB
Output signal Composite-video
S-video Y 0.714 Vp-p/75Ω unbalanced
C 0.286 Vp-p/75Ω unbalanced
VBS 1.0 Vp-p/75Ω unbalanced
White balance
Full auto
Electronic shutter speed
Provided (1/60s or 1/100s)
Nega/posi conversion Enabled (Composite-video, S-video, LCD monitor output)
Enabled (Composite-video, S-video, LCD monitor output)Color/B&W selection
Enlargement of the image Provided (double, can be scrolled)
Zoom 24-time zoom (continuous zoom mode with automatic switching from the
12-time optical zoom plus electronic zoom with 2X function)
