Cleaning the Hook Area
Clean the hook area at least once a month.
Turn the power switch off and unplug the machine.
Remove the needle plate (refer to page 16).
Remove the needle and presser foot.
NOTE:
Do not dismantle the machine in any way other than
as explained in this section.
CARE AND MAINTENANCE
q
q
w
t
e
r
w
z Take out the bobbin and bobbin holder.
q Bobbin holder
x Clean the bobbin holder with a lint brush.
Clean the feed dog and auto thread cutter device with
the lint brush.
w Lint brush
e Feed dog
r Auto thread cutter device
u
y
q
z
x
c
v
c Clean the hook race with a soft cloth.
t Soft cloth
v Insert the bobbin holder so that the knob ts next to
the stopper in the hook race.
Insert the bobbin.
Attach the needle plate, presser foot and needle.
y Knob
u Stopper
WARNING:
Turn the power switch off and unplug the machine
before cleaning.
