ELPRO 105U - Page 70

Chapter 4 Configuration
MAN_105G_1.5 Page 70
Assembly Object, Class 04h
The Assembly Object binds all mapped I/O data. This data is used for I/O connections. This
object is set-up dynamically via databus links through configuration software.
Class Attributes
ID# Name Service Description Semantics
Def,
Min,
Max
Type
01h Revision Get_attribute_all Object
Revision
The revision
attribute containing
the revision of the
object
1,
1,
1
UINT
Input Area, Instance 64h
Note: This data is also available in the vendor specific object: I/O Data Input Mapping Object,
Class A0h, Instance Attribute 01h, and Attribute ID 01h.
ID# Name Service Description Type
03h Data Get_attribute_single The data produced is configured from fieldbus
write mappings to I/O Input Instance 1.
Array of
USINT
Input Area, Instance 65h – 69h
Note: This data is also available in the vendor specific object: I/O Data Input Mapping Object,
Class A0h, Instance Attribute 01h, and Attribute ID’s 01h to 06h.
ID# Name Service Description Type
03h Data Get_attribute_single The data produced is configured from fieldbus
write mappings to I/O Input Instance 2-6.
Array of
USINT
Output Area, Instance 96h
Note: This data is also available in the vendor specific object: I/O Data Output Mapping
Object, Class A1h, Instance Attribute 01h, and Attribute ID 01h.
ID# Name Service Description Type
03h Data Get_attribute_single
Set_attribute_single
The data produced is configured from fieldbus
read mappings from I/O Output Instance 1.
Array of
USINT
Output Area, Instance 97h – 9Bh
Note: This data is also available in the vendor specific object: I/O Data Output Mapping
Object, Class A1h, Instance Attribute 01h, and Attribute ID 01h.
ID# Name Service Description Type
03h Data Get_attribute_single
Set_attribute_single
The data produced is configured from fieldbus
read mappings from I/O Output Instance 2-6.
Array of
USINT
