105U-G Wireless Gateway User Manual
Page 71 © August 2003
I/O Data Input Mapping Object, Class A0h
This object is setup dynamically via fieldbus write mappings through configuration software.
This data is also available as vendor specific Instance Attributes (64h to 69h) in the Assembly
Object.
ID# Name Service Description Semantics
Def,
Min,
Max
Type
01h Revision Get_attribute_all Object
Revision
The revision
attribute
containing the
revision of the
object
1,
1,
1
UINT
Instance Attributes, Instance 01h
ID# Name Service Description Type
01h Data Get_attribute_single The data produced is configured from fieldbus
write mappings to I/O Input Instance 1.
Array of
USINT
02h Data Get_attribute_single The data produced is configured from fieldbus
write mappings to I/O Input Instance 2.
Array of
USINT
…… … … …
06h Data Get_attribute_single The data produced is configured from fieldbus
write mappings to I/O Input Instance 6.
Array of
USINT
