VOLTAGE HARMONICS
 Harmonics ev aluated at in tervals o f 1 0 m in w ithin o bservation window o f 1
week. E valuation a t intervals in w hich v oltage is in side nominal b oundary of
[+15.0%,-15.0%]. D iscarding Intervals with VOLT-INT. Discarding Intervals with
DIPS o r O VER-VOLT. I ndividual H arm is l imited a ccording t o the f ollowing
table: H2<=2. 0%, H3<=5.0%, H 4<=1.0%, H5< =6.0%, H6<=0.5%, H7< =5.0%,
H8<=0.5%, H 9<=1.5%, H10 <=0.5%, H11 <=3.5%, H12< =0.5%, H1 3<=3.0%, . .. T HD
limit is s et 8 .0% ( N2). T HD an d H arms l imits s hall b e k ept at l east 9 5.0% of
time.
INDIVIDUAL HARMONIC LIMITS
