Elstat ems25 Series User Manual

9
www.elstat.io
Note
Cable routing looms must not be secured to hot pipes or vibrating components.
Secure cable routing looms with clips whereever possible.
For security, once fitted, the rear cover can only be removed using atool,such as a small, flat
bladed screwdriver.
Cable routing to the ems controller is critical as
water can trace or follow the cable downwards.
Therefore, immediately prior to the connection to
the controller, a drip loop must be formed in all
wiring as shown to the right

Elstat ems25 Series Specifications

General

Brand	Elstat
Model	ems25 Series
Category	Control Systems
Language	English
