Then install the meter
– gas-tight,
– withthesuppliedaccessories,
– only in flow direction(asmarkedbyanarrowonthemeterhousing),
– only unstressed and
– preferably in horizontal positionwiththeindexatthetop.
The permitted installation/operating positions of the meter are specified on the main
plateinaccordancewiththedesignations“H”,“V”or“H/V”(H=horizontal,V=vertical)
representedinaccordancewithDINEN12261.Ifyouhavespeciedtheinstallationorop-
eratingpositionwhenordering,allattachmentswillhavebeenttedinaccordancewiththe
installationpositionex-works.
 Ifyouwishtoinstall the unit vertically at a later pointandifanoilpumpispresent,theoil
pumpmustalsobettedvertically.Ifthisisnotthecase,youmustturntheoilpumpand
itsoilconnectionlineandanyotherattachments,e.g.volumecorrector,through90°before
installing the meter.
 WerecommendthatyoucontactourCustomerServiceforsuchconversionwork.
– weatherproof.
– Whenttingthesealsandgaskets,ensurethattheyarealigned concentrically and do not
projectintotheowchannel.
7. Pulse Generators
TypeIN-SxxorIN-WLF pulse generators may be plugged
onto the side of the index cover for volume pulse output to
external devices (e.g. a volume corrector).
Fitthepulsegenerator(ifrequired)asfollows:
– Slide both guidesoftheIN-Spulsegeneratorintothe
guide slot on the index cover until the guides can be
heardtoengage(clickingsound).
– Assign the terminalsonthepluginaccordancewith
the pin assignment on the meter/pulse generator.
– Use a screened cable to the external device.
You can use HF pulse generators (Types A1R and A1S)
forhigherfrequencies(ifavailable).HFpulsegeneratorsare
screwedintothemeterhousingpressure-tight.However,the
connection plug can be turned.
