Table of Contents User's Manual
BAB 740
VI
List of Tables
Table 1: Activity LEDs .......................................................... 2—4
Table 2: KEYB (6-pin miniature circular connector) ............. 3—1
Table 3: MOUSE (6-pin miniature circular connector) ......... 3—1
Table 4: ETHERNET (8-pin telephone jack connector) ....... 3—2
Table 5: COM1, COM2 (9-pin min-D connector).................. 3—2
Table 6: PRN (25-pin min-D connector) ............................... 3—3
Table 7: VMEbus Connector P1 (X2001) ............................. 3—4
Table 8: Pin Assignment of Connector P2 (X2002) ............. 3—5
Table 9: SCSI Connector 8-bit X103 (on ADAP-200) .......... 3—6
Table 10: 50-Pin I/O Connector X102 (on ADAP-200)......... 3—7
Table 11: COM3, COM4 (9-pin min-D connector)................ 3—8
Table 12: Pinout Floppy Connector X101 (on ADAP-740)... 3—9
Table 13: Pinout EIDE Connector X105 (on ADAP-740) ... 3—10
Table 14: COM3 and COM4 Connectors X103 and X104
(on ADAP-740) ................................................... 3—11
Table 15: Speaker Connector X106 (on ADAP-740) ......... 3—11
Table 16: PMCE-740 VMEbus Connector P1 (X402) ........ 3—12
Table 17: PMCE-740 PCI Mezzanine Card Connectors
(X101, X102, X201, X202). ................................ 3—13
