ELTEC BAB 740 - Additional I;O; Table 10: 50-Pin I;O Connector X102 (on ADAP-200)

Connector
Assignments
Connector Assignments User's Manual
BAB 740
3—7
3.2.2 Additional I/O
Table 10: 50-Pin I/O Connector X102 (on ADAP-200)
Pin Dir Description Remark
1..23
I/O reserved
24
- Serial Channel 4 GND2
25
- Serial Channel 4 GND1
26
- Serial Channel 4 nc
27
I Serial Channel 4 CTS
28
O Serial Channel 4 TXD (may be changed if a
29
O Serial Channel 4 RTS non standard level-
30
I Serial Channel 4 RXD converter board SILC is
31
- not connected installed)
32
- not connected
33
- Serial Channel 3 GND2
34
- Serial Channel 3 GND1
35
- Serial Channel 3 nc
36
I Serial Channel 3 CTS (may be changed if a
37
O Serial Channel 3 TXD non standard level-
38
O Serial Channel 3 RTS converter board SILC is
39
I Serial Channel 3 RXD installed)
40
- not connected
41
- not connected
42..50
- reserved
Front View
1 2
49
50
