ELTEC BAB 740 - PMCE-740 PCI Mezzanine Card I;O Routing

Connector
Assignments
User's Manual
BAB 740
3—14
Connector Assignments
3.5.3 PMCE-740 PCI Mezzanine Card I/O Routing
Table 18 shows the routing of the PMC I/O Connectors to the
VMEbus P2 Connector
Table 18: PCI Mezzanine Card Back Plane I/O Routing
(X203)
Host Jn24
(X103)
Host Jn14
(X401)
VMEbus P2
(X103)
Host Jn14
(X401)
VMEbus P2
33 1 1C 33 17C
34 2 1A 34 17A
35 3 2C 35 18C
36 4 2A 36 18A
37 5 3C 37 19C
38 6 3A 38 19A
39 7 4C 39 20C
40 8 4A 40 20A
41 9 5C 41 21C
42 10 5A 42 21A
43 11 6C 43 22C
44 12 6A 44 22A
45 13 7C 45 23C
46 14 7A 46 23A
47 15 8C 47 24C
48 16 8A 48 24A
49 17 9C 49 25C
50 18 9A 50 25A
51 19 10C 51 26C
52 20 10A 52 26A
53 21 11C 53 27C
54 22 11A 54 27A
55 23 12C 55 28C
56 24 12A 56 28A
57 25 13C 57 29C
58 26 13A 58 29A
59 27 14C 59 30C
60 28 14A 60 30A
61 29 15C 61 31C
62 30 15A 62 31A
63 31 16C 63 32C
64 32 16A 64 32A
