Connector
Assignments
User's Manual
BAB 740
3—12
Connector Assignments
3.5
PMCE-740 Connectors
Via the PMC Extension Board (PMCE-740) the BAB 740 can be
expanded by two PMC Modules.
3.5.1 PMCE-740 VMEbus Connector P1
Only GND, +5V and +12V are routed from the VMEbus Connector
P1 to the Power Connector X403. No VMEbus Signals are used.
Table 16: PMCE-740 VMEbus Connector P1 (X402)
Pin Row A Row C
1...8
nc nc
9
GND GND
10
nc nc
11
GND nc
12..14
nc nc
15
GND nc
16
nc nc
17
GND nc
18..30
nc nc
31
nc + 12 V (Cam)
32
+ 5 V (Cam) + 5 V (Cam)
