MES1000, MES2000 Ethernet Switches 103
Table 5.98 —EXEC mode commands
Command
Value
Action
show erps [vlan vlan_id]
vlan_id: 1..4094
Request the information on erps general status or specified
ring status.
5.16.9 LLDP protocol configuration
The basic function of Link Layer Discovery Protocol (LLDP) is the exchange of information on status
and specifications between network devices. Information gathered with LLDP is stored on devices and can
be requested by the master computer via SNMP protocol. Thus, this information allows to model the
network topology on the master computer.
Switches support transmission of standard and optional parameters, such as:
Device name and description
Port name and description
MAC/PHY information
etc.
Global configuration mode commands
Command line request in global configuration mode appears as follows:
console(config)#
Table 5.99 —Global configuration mode commands
Command
Value/Default value
Action
lldp run
enabled
Enable LLDP utilization by the switch.
no lldp run
Disable LLDP utilization by the switch.
lldp timer seconds
(5..32768)/30 seconds
Define the frequency of LLDP information updates
transmission by the device.
no lldp timer
Restore the default value.
lldp hold-multiplier number
(2..10)/4
Define the amount of time for the receiving device to keep
LLDP packets before dropping them.
This value will be transmitted to the receiving side in LLDP
update packets; is a divisibility for LLDP timer. Thus, LLDP
packet lifetime is calculated by the equation TTL = min(65535,
LLDP-Timer * LLDP-HoldMultiplier)
no lldp hold-multiplier
Restore the default value.
lldp reinit seconds
(1..10)/2 seconds
Minimum amount of time, that LLDP port will wait before LLDP
reinitialization.
no lldp reinit
Restore the default value.
lldp tx-delay seconds
(1..8192)/2 seconds
Define the delay between the subsequent LLDP packet
transmissions, initiated by changes of values or status in local
LLDP MIB database.
It is recommended to set this delay less than 0.25*
LLDP-Timer.
no lldp tx-delay
Restore the default value.
lldp lldpdu
{filtering | flooding}
filtering
Define the LLDP packet processing mode, when LLDP is
disabled on the switch:
- filtering—LLDP packets are filtered, if LLDP is disabled on the
switch
- flooding—LLDP packets are transmitted, if LLDP is disabled
on the switch
no lldp lldpdu
Restore the default value.
lldp med fast-start repeat-
count number
(1..10)/3
Set the PDU LLDP repetition quantity for quick start defined by
LLDP-MED.
no lldp med fast-start
repeat-count
Restore the default value.
lldp med network-policy
number application
number: (1..32);
application: (voice,
Define the rule for network-policy parameter (device network
policy). This parameter is optional for LLDP MED protocol
