108 MES1000, MES2000 Ethernet Switches
Auto-negotiation
Advertised Capabilities
Define modes supported by automatic port discovery function.
Operational MAU type
Working device MAU type.
5.16.10 OAM protocol configuration
Ethernet OAM (Operation, Administration, and Maintenance), IEEE 802.3 ah—channel-level
functions for data transmission, represent channel state monitoring protocol. This protocol is used for
transmission of channel status information between directly connected Ethernet devices using OAM
protocol data units (OAMPDU). Both devices should support IEEE 802.3ah standard.
Ethernet interface configuration mode commands
Command line request in Ethernet interface configuration mode appears as follows:
console(config-if)#
Table 5.104 —Ethernet interface configuration mode commands
Command
Value/Default value
Action
ethernet oam
-/disabled
Enable Ethernet OAM support for the port.
no ethernet oam
Disable Ethernet OAM support for the configured port.
ethernet oam link-monitor
frame threshold count
1..65535/1
Define the error quantity threshold for the specific period
(period is defined with ethernet oam link-monitor frame
window command).
no ethernet oam link-
monitor frame threshold
Restore the default value.
ethernet oam link-monitor
frame window window
10..600/100 ms
Define the time period for error quantity count.
no ethernet oam link-
monitor frame window
Restore the default value.
ethernet oam link-monitor
frame-period threshold
count
1..65535/1
Define the 'frame-period' event threshold for the specific
period (period is defined with ethernet oam link-monitor
frame-period window command).
no ethernet oam link-
monitor frame-period
threshold
Restore the default value.
ethernet oam link-monitor
frame-period window
window
1..65535/10000
Define the time interval for 'frame-period' event (in frames).
no ethernet oam link-
monitor frame-period
window
Restore the default value.
ethernet oam link-monitor
frame-seconds threshold
count
1..900/1
Define the 'frame-period' event threshold for the specific
period (period is defined with ethernet oam link-monitor
frame-seconds window command) in minutes.
no ethernet oam link-
monitor frame-seconds
threshold
Restore the default value.
ethernet oam link-monitor
frame-seconds window
window
100..9000/100 ms
Define the time interval for 'frame-period' event.
no ethernet oam link-
monitor frame-seconds
window
Restore the default value.
ethernet oam mode
{active|passive}
-/active
Set OAM protocol operation mode.
- active—switch sends OAMPDU constantly
- passive—switch will send OAMPDU only when OAMPDU are
present from the opposite device.
no ethernet oam mode
Restore the default value.
ethernet-oam remote-failure
-/enabled
Enable 'remote-failure' events support and processing.
