ELTEX MES1000

114 MES1000, MES2000 Ethernet Switches
Table 5.112 —Global configuration mode commands
Command
Value/Default value
Action
voice vlan aging-timeout
timeout
timeout: (1..43200/1440)
Set the timeout for port that belongs to the voice-vlan. If there
were no frames with VoIP equipment OUI for the definite
time, the voice vlan will be removed from the current port.
no voice vlan aging-
timeout
Restore the default value.
voice vlan cos cos [remark]
cos:(0-7)/6
Set COS to mark the frames belonging to Voice VLAN.
no voice vlan cos
Restore the default value.
voice vlan id vlan_id
vlan_id:(2 .. 4094)
Set VLAN identifier for Voice VLAN
no voice vlan id
Remove VLAN identifier for Voice VLAN
To remove VLAN identifier, disable voice vlan
function first on all ports.
voice vlan oui-table
{add oui|remove oui}
[descript]
oui: the first 3 bytes of the
MAC address
descript: (1..32) characters
Allow to edit OUI table.
- oui—first 3 bytes of MAC address
- descript—OUI description
no voice vlan oui-table
Remove all user changes made to OUI table.
Ethernet interface configuration mode commands
Command line request in Ethernet interface, port group interface configuration mode appears as
follows:
console(config-if)#
Table 5.113 —Ethernet interface configuration mode commands
Command
Value/Default value
Action
voice vlan enable
Disabled
Enable Voice VLAN for the port.
no voice vlan enable
Disable Voice VLAN for the port.
voice vlan cos mode
{src|all}
-
Enable traffic labelling for all frames or for the source only.
no voice vlan cos mode
Restore the default value.
voice vlan secure
Disabled
Enable the secure mode for VLAN. Command is applied only to
those ports, that have been added to Voice VLAN
automatically.
no voice vlan secure
Restore the default value.
EXEC mode commands
Command line request in EXEC mode appears as follows:
console#
Table 5.114 —EXEC configuration mode commands
Command
Value/Default value
Action
show voice vlan
[gigabitethernet gi_port |
fastethernet fa_port |
port-channel group]
gi_port: (1..3/0/1..28);
fa_port: (1..3/0/1..24);
group: (1..8)
Show Voice VLAN state.
