144 MES1000, MES2000 Ethernet Switches
with integral byte quantity (checksum verification errors—FCS) or with non-integral
byte quantity (alignment errors).
Quantity of packets received during the record generation period, with length more
than 1518 bytes (w/o frame bits, but with checksum bits), that have invalid
checksum with integral byte quantity (checksum verification errors—FCS) or with
non-integral byte quantity (alignment errors).
The quantity of detected events when the packets were dropped during the record
generation period.
Show the alarm signal summary table:
console# show rmon alarm-table
Index OID Owner
----- -------------------------- -------
1 1.3.6.1.2.1.2.2.1.10.1 CLI
2 1.3.6.1.2.1.2.2.1.10.1 Manager
Table 5.154 —Description of results
Index, the unique identifier of the record
User, that created the record.
Show alarm events configuration with the index '1':
console# show rmon alarm 1
Alarm 1
-------
OID: 1.3.6.1.2.1.2.2.1.10.1
Last sample Value: 878128
Interval: 30
Sample Type: delta
Startup Alarm: rising
Rising Threshold: 8700000
Falling Threshold: 78
Rising Event: 1
Falling Event: 1
Owner: CLI
Table 5.155 —Description of results
Variable value at the last control interval. If the default variable collection method is
absolute, it will be absolute variable value; if the method is delta, it will be the
difference between the variable values at the start point and the end point of the
control interval.
Time interval in seconds when data is collected and compared to upper and lower
thresholds.
Variable collection and value calculation method for the threshold comparison.
absolute method—absolute value of the selected variable will be compared to the
threshold at the end point of the control interval. delta method—value of the
variable collected in the last selection will be deducted from the current value and
