MES1000, MES2000 Ethernet Switches 159
output-power: (-40000-
8200) mdBm
temperature: (-127-127) °C
voltage: (0-6550000) uV
- voltage
optical-transceiver threshold
values parameter
Remove specified thresholds for the selected parameter.
Default values are not defined.
Command line request in EXEC mode appears as follows:
console>
Table 5.181 —Optical transceiver diagnostics command
Command
Value
Action
show fiber-ports optical-
transceiver [interface
{gigabitethernet gi_port |
fastethernet fa_port} ]
[detailed]
gi_port: (1..3/0/1..28);
fa_port: (1..3/0/1..24).
Show optical transceiver diagnostics results.
- detailed—detailed diagnostics, transceiver eeprom
parameters.
Example execution of the command
console# show fiber-ports optical-transceiver interface gi1/0/24 detailed
Port Temp Voltage Current Output Input LOS Transceiver
[C] [V] [mA] Power Power Type
[mW / dBm] [mW / dBm]
----------- ------ ------- ------- ------------- ------------- --- -------------
gi1/0/24 58 3.25 20.09 0.58 / -2.30 0.00 / -40.00 Yes Fiber
Temp - Internally measured transceiver temperature
Voltage - Internally measured supply voltage
Current - Measured TX bias current
Output Power - Measured TX output power in milliWatts
Input Power - Measured RX received power in milliWatts
LOS - Loss of signal
N/A - Not Available, N/S - Not Supported, W - Warning, E - Error
Transceiver information:
Vendor name: OEM
Serial number: SX31221300026
Connector type: LC
Type: SFP/SFP+
Compliance code: 10GBASE-LR
Laser wavelength: 1310 nm
Transfer distance: 10000
Diagnostic: supported
Table 5.182—Optical transceiver diagnostics parameters
Parameter
Value
Temp
Transceiver temperature.
Voltage
Transceiver power voltage.
Current
Current deviation for transmission.
Output Power
Output power for transmission (mW).
Input Power
Input power for receiving (mW).
LOS
Loss of signal.
