176 MES1000, MES2000 Ethernet Switches
Authentication Method
Established session authentication method.
Termination Cause
The reason for closing session.
State
The current value of the authentication state engine and output state engine.
Authentication success
Quantity of messages about the successful authentication received from the server.
Authentication fails
Quantity of messages about the unsuccessful authentication received from the
server.
VLAN
VLAN group assigned to the user.
Filter ID
Filter group identifier.
 Show statistics on 802.1X for the Ethernet interface 13.
console# show dot1x statistics interface gigabitethernet 1/0/13
EapolFramesRx: 12
EapolFramesTx: 8
EapolStartFramesRx: 1
EapolLogoffFramesRx: 1
EapolRespIdFramesRx: 4
EapolRespFramesRx: 6
EapolReqIdFramesTx: 3
EapolReqFramesTx: 5
InvalidEapolFramesRx: 0
EapLengthErrorFramesRx: 0
LastEapolFrameVersion: 1
LastEapolFrameSource: 00:00:02:56:54:38
Table 5.203 Description of command execution results
Parameter
Description
EapolFramesRx
The quantity of valid EAPOL (Extensible Authentication Protocol over LAN) packets
of any type received by the current authenticator.
EapolFramesTx
The quantity of valid EAPOL packets of any type sent by the current authenticator.
EapolStartFramesRx
The quantity of EAPOL Start packets received by the current authenticator.
EapolLogoffFramesRx
The quantity of EAPOL Logoff packets received by the current authenticator.
EapolRespIdFramesRx
The quantity of EAPOL Resp/Id packets received by the current authenticator.
EapolRespFramesRx
The quantity of EAPOL response packets (except for Resp/Id) received by the
current authenticator.
EapolReqIdFramesTx
The quantity of EAPOL Resp/Id packets sent by the current authenticator.
EapolReqFramesTx
The quantity of EAPOL request packets (except for Resp/Id) sent by the current
authenticator.
InvalidEapolFramesRx
The quantity of EAPOL packets with unrecognised type received by the current
authenticator.
EapLengthErrorFramesRx
The quantity of EAPOL packets with incorrect length received by the current
authenticator.
LastEapolFrameVersion
EAPOL version received in the last packet.
LastEapolFrameSource
Source MAC address received in the last packet.
5.27.2.2 Advanced authentication
Advanced dot1x settings allow to authenticate multiple clients connected to the port. There are two
authentication options: The first authentication option, when the port-based authentication requires only
a single client authentication so that all clients will be able to access the system (multiple hosts mode),
and the second option, when the authentication requires authentication of all clients connected to the
