Transmitted Pause Frames: 0
Table 5.35 —Description of counters
Counter
Description
InOctets
Quantity of bytes received.
InUcastPkts
Quantity of unicast packets received.
InMcastPkts
Quantity of multicast packets received.
InBcastPkts
Quantity of broadcast packets received.
OutOctets
Quantity of bytes sent.
OutUcastPkts
Quantity of unicast packets sent.
OutMcastPkts
Quantity of multicast packets sent.
OutBcastPkts
Quantity of broadcast packets sent.
Alignment Errors
Quantity of frames, that failed integrity verification (with the byte quantity
mismatching the length) and checksum verification (FCS).
FCS Errors
Quantity of frames with the byte quantity matching the length, that failed checksum
verification (FCS).
Single Collision Frames
Quantity of frames involved in a single collision, but transmitted successfully later.
Multiple Collision Frames
Quantity of frames involved in multiple collisions, but transmitted successfully later.
Deferred Transmissions
Quantity of frames with the first transmission attempt delayed due to busy
communication medium.
Late Collisions
Quantity of cases, when collision is identified after transmission of the first 64 bytes
of the packet to the communication link (slotTime).
Excessive Collisions
Quantity of frames, that were not sent due to excessive number of collisions.
Carrier Sense Errors
Quantity of cases, when carrier control state was lost or not approved in the frame
transmission attempt.
Oversize Packets
Quantity of received packets, which size exceeds the maximum allowed frame size.
Internal MAC Rx Errors
Quantity of frames, that were not received successfully due to internal receiving
error on the MAC level.
Symbol Errors
For the interface operating in 100Mbps mode, the quantity of cases, when
inappropriate data symbol was found, while the correct carrier was represented.
For the interface operating in 1000Mbps mode, the quantity of cases, when
receiving instrumentation was busy for the time equal or greater than the slot size
(slotTime), and during which there was one or more events, that forced PHY to
return the data reception error or carrier extend error on GMII.
For the interface operating in full-duplex 1000Mbps mode, the quantity of cases,
when receiving instrumentation was busy for the time equal or greater than the
minimum frame size (minFrameSize), and during which there was one or more
events, that forced PHY to return the data reception error on GMII.
Received Pause Frames
Quantity of received control MAC frames with PAUSE operation code.
Transmitted Pause
Frames
Quantity of sent control MAC frames with PAUSE operation code.
 Show jumbo frame settings for the switch:
console# show ports jumbo-frame
Jumbo frames are disabled
Jumbo frames will be disabled after reset
