EM TEST AutoWave

Manual for Operation V 5.9.1 25 / 45

3.2.1.1.

Menu Wave Generator

Functions

- Selecting files

- Play files

The output active LED indicates the output channel(s) of the selected

file.

Note : Files with multiple waves indicates all used output channels. The

software AutoWave delivers the detailed information about the

wave on each channel.

status blinking : Running

off : Ready to start

A selected wave will be repeated according to the selected number of “Events”. The time counter begins after

each restart at zero.

Key functions

Select a file

1. Select with the buttons the desired file.

2. Press buttons to play and stop the file.

Start, Break and Continue
