EM TEST AutoWave User Manual

EM TEST AutoWave
Manual for Operation V 5.9.1 35 / 45
5.
Technical data
AutoWave
Number of output channels
2 channels;
2 additional channels can be added as an option (ExtBoard)
Output voltage
10V, unipolar or bipolar
Resolution
16 Bit
Frequency range
DC ... 50kHz ( 10samples per sinus period at 500kSample/sec )
Output Range
10V
Output Type
Single Ended
Resolution
16 bit
Differential linearity error
8 LSB (DAC)
Integral linearity error
4 LSB (DAC)
Accuracy
(0.5% + 5mV)
Maximum Sampling Rate
500kS/s (Accuracy:  50ppm) for one channel
Transition Time
< 5s Tested with 1kHz Square wave (20Vpp / without Offset).
Output Impedance
50
Max Output Current
10mA Output short circuit protected.
Wave Forms
Segment types
DC voltage
Sine
Sine sweep ( log, linear )
Damp Sine
Sine Ramp
Square wave
Profile
Triangular
Sawtooth
Ramp up / Ramp down
Step
Exponential
Calculated based on mathematical formula
Segment duration
Unlimited
Segments per wave form
20-30 depends on the complexity of the segment
WaveRecorder
Number of input channels
2 channels (ExtBoard for AutoWave required)
Input voltage ranges
5V, 10V, 20V, 50V and 100V;
unipolar or bipolar
Resolution
16 Bit
Accuracy
better than 0.2%
Frequency range
DC ... 50kHz
Sampling rate (selectable)
5S/s...500kS/s (one channel)
5S/s...100kS/s (two or four channels)
Storage
File size max. 1 GByte
