Manual for Operation V 5.9.1 36 / 45
Display and Controls
Display
Text LCD 2 lines, 40 characters
LED indicators
Power On
Active channel 6 (2 inputs, 4 outputs)
Trigger
Running status
Operation
6 function keys
Trigger and DUT Monitoring
Trigger
2 inputs, 2 outputs
DUT monitoring
2 inputs, configurable
Control
Computer
PC 104 computer
AMD Microprocessor 100MHz
32MB RAM
Operating system
Linux, with Real time extension
DSP Signal processor
Motorola DSP 56303
Data storage
Hard disk 40GB ( standard )
Interfaces
GPIB Address 1...30
Ethernet
USB (for memory stick and ext. hard disc) I max. 500mA
CAN bus (for trigger)
Frame bus (internal system bus)
Storage battery
Lithium battery
Type: CR2032 3V, 235mAh 20.0 x 3.2 mm
Buffer battery ( option )
Rechargeable battery 12V, 2000mAh NiMH
Environmental Hard disk
Temperature
operating
5...40°C
storage
-20...60°C
gradient
20°C / hour
Humidity
10%...90% non-condensing
Vibration
Operating
1.0G
Non Operating
5.0G
Shock
Operating
225G ( 2ms)
Non Operating
900G ( 1ms)
General Data
Safety design
per IEC 1010, EN 61010
Power supply
AC: 90V ... 250V , 47Hz...63Hz
DC: 12V ... 32V, filtered and buffered
Fuses
F1 : 3.15 A slow blow ( DC )
F2 : 1.00 A slow blow ( AC )
Power requirement
40W max.
Dimension (W x H x D)
380 x100 x 390 mm
Weight
6kg
= => not relevant data for the standards can be changed by the manufacturer <= =
