DAE2P/DAE3P Hardware Reference
About DAE2P and DAE3P disk enclosures
Figure 1-9 Power/cooling module LEDs
A captive screw on the power/cooling module locks it into place to
ensure proper connection to the midplane. You can add or remove
one power/cooling module in a DAE2P/DAE3P while the system is
powered up.
!!
!!
!
EXP PRI
EXPPRI
#
!
EXP PRI
EXPPRI
#
A
B
!!
Power LED (Green)
Power Fault LED (Amber)
Blower Fault LED (Amber)
EMC3211
