Enclosure specifications
A-3
Technical specifications
Size and weight
Drive type
The DAE2P/DAE3P uses 3.5-inch (8.75 cm) by 1.0-inch (2.54 cm) disk
drives. Standard, Fibre Channel drives are 12-volt, and support the
Fibre Channel interface. SATA drives (DAE3P only) are 12- and 5-volt
and support the SATA 3 Gb/s interface; a paddle card on the drive
converts the assembly to 12-volt, 4 Gb/s Fibre Channel operation.
Each drive slot provides an average maximum of 16 W drive module
power.
Refer to the EMC Storage Systems CX-Series Disk and FLARE OE Matrix
for a list of supported drives.
LCC FC-AL interface
Connectors are shielded HSSDC2 (High Speed Serial Data
Connector).
Copper cabling
HSSDC2
Requirement Measurement
Height 133.35 mm (5.25 in)
3 NEMA units including mounting hardware
Width 450 mm (17.72 in)
Depth 355.6 mm (14 in)
Weight 30.91 kg (68 lbs) maximum configuration;
1.1 kg (2.4 lbs) per FC disk module x15 max = 16.4 kg (36 lbs);
0.7 kg (1.5 lbs) per link control card x 2 =1.4 kg (3 lbs)
2.5 kg (5.5 lbs) per power supply x 2 = 5.0 kg (11 lbs)
8.2 kg (18 lbs) chassis and midplane
Type: Shielded, 150 Ω differential, shield bonded to plug connector shell (360°)
FC-PI-2 Standard, Revision 13 or higher for HSSDC2
SFF-8470 150 specification for SFP transceiver
HSSDC2 -HSSDC2 for DAE2P/DAE3P-DAE2P/DAE3P connection;
HSSDC2-SFP for DAE2P/DAE3P to CX3-series back-end
HSSDC-HSSDC2 for connection to CX-series DPE, SPE, or DAE2
Length: 2 meters (6.6 feet);5 meters (16.5 feet) and 8 meters (26.4 feet)
Maximum 5-meter support for SFP-HSSDC2 connection
