WEEE Disassembly Instructions for the
HD400 Disk Processor Enclosure
Figure 7b – Internal materials within the Suitcase
Table 6 Components on the Power Supply
Item
Component
Item
Components
2
Fan Modules
20
Expander Board Interposer
Board
3
Power Supplies
21
PCBs (5)
18
Chassis
22
DIMMS (6)
19
Suitcase Cover
23
CPU
20
21
22
23
